Stanton DJC.4 - Page 14

MIDI MAP
CENTER DECK
LEDs LED ON LED OFF
TX 09,9n,2E,7F
0
9,9n,2E,00
FX 09,9n,2F,7F
0
9,9n,2F,00
VIDEO_XF 09,9n,24,7F
0
9,9n,24,00
XF_LINK 09,9n,25,7F 09,9n,25,00
MASTER_METER_L1 0B,Bn,03,0C 0B,Bn,03,00
MASTER_METER_L2 0B,Bn,03,18 0B,Bn,03,00
MASTER_METER_L3 0B,Bn,03,24
0
B,Bn,03,00
MASTER_METER_L4 0B,Bn,03,30 0B,Bn,03,00
MASTER_METER_L5 0B,Bn,03,3C 0B,Bn,03,00
MASTER_METER_L6 0B,Bn,03,48
0
B,Bn,03,00
MASTER_METER_L7 0B,Bn,03,54 0B,Bn,03,00
MASTER_METER_L8 0B,Bn,03,60 0B,Bn,03,00
MASTER_METER_L9 0B,Bn,03,6C 0B,Bn,03,00
MASTER_METER_LA 0B,Bn,03,78 0B,Bn,03,00
MASTER_METER_R1 0B,Bn,04,0C 0B,Bn,04,00
MASTER_METER_R2 0B,Bn,04,18 0B,Bn,04,00
MASTER_METER_R3 0B,Bn,04,24 0B,Bn,04,00
MASTER_METER_R4 0B,Bn,04,30 0B,Bn,04,00
MASTER_METER_R5 0B,Bn,04,3C 0B,Bn,04,00
MASTER_METER_R6 0B,Bn,04,48
0
B,Bn,04,00
MASTER_METER_R7 0B,Bn,04,54 0B,Bn,04,00
MASTER_METER_R8 0B,Bn,04,60 0B,Bn,04,00
MASTER_METER_R9 0B,Bn,04,6C 0B,Bn,04,00
MASTER_METER_RA 0B,Bn,04,78 0B,Bn,04,00
DECK A DECK B DECK C DECK D CENTER
Mode1(n) 0 1 2 3
0
Mode2(n) 4 5 6 7
4
Mode3(n) 8 9 10 11
8
Mode4(n) 12 13 14 15 12
