Star Micronics NX-1500 - Defective Interface Operation

– 63 –
TROUBLESHOOTING
4-5. Defective Interface Operation
Check I/F cable.
Check or replace
1) IC3
2) Gate array
3) CPU
NO
YES
START
Set at on line
Start print program
of host computer.
Is I/F
signal normal? *5
YES
Incorrect print
generated?
NO
Check operation
END
