TUP500 Series Product Specifications
4-1
4. EXTERNAL SPECIFICATIONS
4.1. External Specifications
4.1.1. External Dimensions
Unit Name Width × Depth × Height
TUP592-24 Approx. 160.0 mm x 234.1 mm x 179.0 mm
TUP542-24 Approx. 160.0 mm x 185.0mm x 179.0 mm
TMP542-24-A Approx. 134.9 mm x 100.6 mm x 102.8 mm
Notes: Dimensions above do not include roll paper or accessories (including optional parts).
4.1.2. External Drawing
See Fig. 4.1.2.A and Fig. 4.1.2.B. on the separate sheets.
4.1.3. Mass
Unit Name Mass
TUP592-24 Approx. 2.5 kg
TUP542-24 Approx. 2.3 kg
TMP542-24A Approx. 0.7 kg
Notes: Weights do not include roll paper or accessories (including optional parts).
