No. Code No. Description Specification Qty. Remark
1
03.01049
Hexagon socket head cap screws
M6×20
1
GB/T 70.1-2000
2
03.0257
Hexagon nut
M6
1
GB/T 6170-2000
3
33.050.0001
33.050.0002
Main frame welding （550Type
）
Main frame welding （685Type
）
1
4 30.44.037 Front sealing plate 1
5
03.0087
Hexagon socket head screw
M6×10
4
GB/T 70.3-2000
6 02.0243 Hexagon lock nut M10 2 GB/T 6184-2000
7 30.28.0137 Roller 2
8 03.03820 Hexagon Head bolt full thread M10×60 2 GB/T 5783-2000
9 82.45.0008 Push rod assembly 2
10
30.01.3311
30.01.0154
Back shaft（550 Type）
Back shaft（685 Type）
1
11 03.0024 Hole Circlip Φ25 2 GB 893.1-86
12
82.451.0001
82.451.0002
Ring rod assembly（550 Type）
Ring rod assembly（685 Type）
1
13
30.01.6569
Axle
2
14
03.0305
Elastic cylindrical pin
Φ5×30
2
GB/T879.2-2000
BODY ASSEMBLY
20
