Stark 58108 User Manual

No. Code No. Description
Specification
Qty. Remark
1
CDD-ME2T-685-35-0001
Plunger lever
1
2
DHS35
Dustband
1
3
GB/T3452.1-1992
O ring
Φ41×3.5
1
4
UHS35
Seal ring
1
5
CDB-MA2T-685-0050
Compound gasket
Φ10
3
6 CDB-MA2T-685-0060 The little screw 3
7
CDD-ME2T-685-35-0002
Outer cylinder
1
8
GB/T3452.1-1992
0 ring
Φ69×2.5
1
9
GB/T3452.1-1992
0 ring
Φ42×2
2
10
CDB-MA2T-685-35-0003
Inner cylinder
1
11
CDD-ME2T-685-0020
Small pump core
1
12 CDB-MA2T-685-0100 Spring gland 1
13 CDD-ME2T-685-0030 The pump core spring 1
14
CDB-MA2T-685-0120
Dustband
1
15
CDB-MA2T-685-0050
Compound gasket
Φ10
3
16
CDB-MA2T-685-0060
Small pump core
3
17
CDB-MA2T-685-0180
Steel ball
Φ4.75
1
18
C-8
Safety seat
1
19
C-17
Relief valve spring
1
20 C-9 Safety valve adjusting screw 1
21
CDD-ME2T-685-0040
Switch plate
1
22
Nut
M8
1
23
Screw
M8×65
1
24 GB/T73-1985
Slotted set screws with cone
point
M6×25
1
25
GB/T41-2000
Hex nut
M6
1
26
C-11
Copper nut
1
27
CDB-MA2T-685-0240
Compound gasket
Φ20
2
28
GB/T3452.1-1992
O ring
Φ11×1.9
2
29 CDD-ME2T-685-0050 Plunger 1
30
C-15
Plunger spring
1
31
CDB-MA2T-685-0270
Steel ball
Φ6.35
1
32
PLUG 1/4
2
33
GB/T3452.1-1992
O ring
Φ14×1.9
2
34
CDD-ME2T-685-35-0060
Oil cylinder welded
1
35
CDB-MA2T-685-35-0170
Stop lever
Φ8×100
1
36 H-3290 Valve body 1
37
H-3310
Valve element
1
38
H-3320
Valve element spring
1
39 C-7 Plug screw 1
