Stark 58108 User Manual

ELECTRICAL ASSEMBLY
No. Code No. Description
Specification
Qty. Remark
1
02.XDC.3415
LI
-Battery
24V/20AH
1
1.5t/1.8t std
02.XDC.3423
24V/30AH
1.5t/1.8t opt
02.XDC.3416
24V/40AH
02.XDC.3417
24V/60AH
02.XDC.3418
48V/20AH
2.0t std
02.XDC.3424
48V/30AH
2.0t opt
2
02.KZQ.2151
Controller
1212P-2501
1
1.5t/1.8t
02.KZQ.2377
1212C-2506
02.KZQ.2376
D2-3101
02.KZQ.2374
1226BL
-410
1
2t
02.KZQ.2156
1226BL-415
1
3 03.01410
Hexagon socket head cap
screws
M5×25
2 GB/T 70.1-2000
4
03.0007
Spring washer
Φ5
4
GB/T 93-1987
5 02.01.3057
Fuse base
SYY
1
6
03.0055
Flat washer
Φ5
2
GB/T 95-2002
7 03.0133
Hexagon socket head cap
screws
M5×16
2 GB/T 70.1-2000
8
19.03450
Fuse
CNP-100A
1
9
03.02151
Cross recess pan head screw
M3×8
2
GB/T 818-2000
10
19.03620
Horn
24V
1
1.5t/1.8t
19.03621
48V
2.0t
40
