AVR200 and AVR300 User Guide
25 6106 Revision D
4.5 Computer and Software Specifications
The following table provides the computer and software specifications for the AVR systems.
Feature
Specification
Computer Hardware
System PC with 8 GB RAM and i7 Intel processor
Computer interface
24-inch touch screen monitor
Computer Interfaces
Ethernet (1 GB/sec), Wi-Fi, four USB 2.0 ports, four USB 3.0
ports
Data Storage
128 GB SSD
Operating System
Windows
®
10
Application Software
MetLogix M3 CNC metrology software and DXF/FOV option
pack
Geometrical Constructs
2D geometries plus height
Comparison to CAD Files
DXF CAD file import, automatic comparison to CAD files
4.6 Touch Probe Specifications
The touch probe includes the following components and specifications.
• Probe body
• Probe module - seven variants enable numerous applications
• Module changing rack for automatic operation
• Interfaces with Renishaw PI 7-3, PI 200-3 and UCC controllers
Feature
Specification
Sense directions
±X, ±Y, ±Z
Interface
PI 7-3, PI 200-3, UCC controllers
Pre-travel variation
LF: ±0.60 µm (± 0.000023 in)
SF / EM1 / EM2: ±0.80 µm (± 0.000032 in)
MF: ±1.00 µm (± 0.000039 in)
EF: ±2.00 µm (± 0.000079 in)
6W: ±1.50 µm (±0.000058 in)
Unidirectional repeatability
LF / SF / EM1 / EM2: ±0.35 µm (± 0.000014 in)
MF: ±0.50 µm (± 0.000020 in)
EF: ±0.65 µm (± 0.000026 in)
6W: ±1.00 µm (± 0.0000395 in)
Repeatability of stylus
changing
MCR20: ±0.50 µm (± 0.000020 in)
Manual: ±1.00 µm (± 0.000040 in)
