Rev: November 9, 2007
Cascaded Installation - cont’d
VGA Signal
Source
Support, Warranty Information, and Regulatory Compliance Statement
If you ever need help with your product, visit www.startech.com/support and access our
comprehensive selection of online tools, documentation, and downloads. This product is
backed by a one year warranty. In addition, StarTech.com warrants its products against
defects in materials and workmanship for the periods noted, following the initial date of pur-
chase. During this period, the products may be returned for repair, or replacement with equiva-
lent products at our discretion. The warranty covers parts and labor costs only. StarTech.com
does not warrant its products from defects or damages arising from misuse, abuse, alteration,
or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or
their officers, directors, employees or agents) for any damages (whether direct or
indirect, special, punitive, incidental, consequential, or otherwise), loss of profits,
loss of business, or any pecuniary loss, arising out of or related to the use of the
product exceed the actual price paid for the product. Some states do not allow the
exclusion or limitation of incidental or consequential damages. If such laws apply,
the limitations or exclusions contained in this statement may not apply to you.
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful inter-
ference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Function ST122W ST124W ST128W
Display Connections 2 4 8
Connectors
Video In 1 x HDB15 Male
Video Out
2 x HDB15 Female
4 x HDB15 Female
8 x HDB15 Female
Power 1 x DC Jack
LEDs Power 1
Video Bandwidth 250MHz 200MHz
Resolution 1920 x 1440 @75Hz 1600 x 1200 @ 60Hz
Signal Range Up to 65m (210’)
Power Consumption DC9V, 1.35W (Max.) DC9V, 2.25W (Max.) DC9V, 2.5W (Max.)
Environment
Operating
Temperature
0 - 50°C
Storage
Temperature
-20°C - 60°C
Humidity 0 - 80% RH, Non-condensing
Physical
Properties
Weight 0.14kg 0.15kg 0.22kg
Dimensions 11.45 x 8.75 x 3.33cm (L x W x H) 15.59 x 9.79 x 3.33cm
Specifications
