Steelman JS647509 - Page 2

JS647509
JS647510
TABLE OF
CONTENTS
SPECIFICATIONS
SAFETY &
WARNING
INFORMATION
Specifications..........................................................................................................................
Safety and Warning Information..........................................................................................
Setup, Operation & Preventive Maintenance.....................................................................
Inspection, Storage & Troubleshooting..............................................................................
Exploded View & Replaceable Part Numbers....................................................................
Warranty Information............................................................................................................
Preventive Maintenance Record Log..................................................................................
2
2
3-4
4-5
6
7
8
2
WARNING
This is the safety notification symbol. This symbol will notify you of any potential
injury hazards. Please follow all instructions that follow this symbol to avoid
possible injuries or death.
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
Before operating this device, be sure to read all content within this manual, ensuring
that you understand the operating procedures, maintenance requirements and all
safety warnings. The owner and/or operator shall have an understanding of the
product, its operating characteristics, and safety operating instructions before
operating this device. Safety information shall be emphasized and understood. If the
operator is not fluent in English, the product and safety instructions shall be read to
and discussed with the operator in the operator’s native language by the purchaser/
owner or his designee, making sure that the operator comprehends their contents.
• Study, understand, and follow all instructions before operating this device.
• Do not exceed rated capacity.
• Use only on a hard, level surface.
• Support the vehicle with appropriate means immediately after lifting.
• Do not move or dolly the vehicle while it is on the jack.
• Lift only on areas of the vehicle as specified by the vehicle manufacturer.
• No alterations shall be made to this product.
• Failure to heed these markings may result in serious personal injury and/or
property damage.
WARNING
Indicates a hazardous situation. If proper steps are not followed, death or serious injury
could result.
Capacity
5 Ton
10 Ton
5-7/8"
6-5/16"
27"
27"
45-1/2"
45-1/2"
59-1/4"
64-7/16"
14-3/8"
19-1/4"
230 Lb.
350 Lb.
Min.
Height
Max
Height
Handle
Length
Overall
Length
Overall
Width
Shipping
Weight
