- 15 -- 14 -
Material
Rigid PVC
Rigid PE
(HDPE)
Polyethylene
PP
Polypropylene
ABS
Applications
Pipes, fittings, tiles, structural sections,
industrial mouldings
300 °C welding temperature
Tubs, baskets, canisters,
insulating material, piping
300 °C welding temperature
High-temperature drainpipes, seat buckets,
packagings, automotive parts
250 °C welding temperature
Automotive parts, equipment enclosures, cases
350 °C welding temperature
Characteristic signs
Chars in the flame,
pungent odour;
clattering sound
Bright yellow flame,
drips carry on burning, smells of
extinguished candle; clattering sound
Bright flame with blue core,
drips continue to burn, pungent odour;
clattering sound
Black, fluffy smoke,
sweetish odour;
clattering sound
Guide for selecting the right type of welding rod when welding plastics
Accessories (see illustrations on the cover)
Y
our retailer has a wide range of accessories for you to
choose from.
1
Surface nozzle 50 mm Prod. No. 070113
2 Surface nozzle 75 mm Prod. No. 070212
3
Window nozzle 50 mm Prod. No. 070311
4 Window nozzle 75 mm Prod. No. 070410
5
Paint scraper kit Prod. No. 010317
6 Reflector nozzle Prod. No. 070519
7 Crimp connectors
Ø
0.5-1.5 Prod. No. 006655
Ø 1.5-2.5 Prod. No. 006648
Ø
0.1-0.5 – Ø 4.0-6.0 Prod. No. 006662
8 Heat-shrinkable tubing
4.8-9.5 mm Prod. No. 071417
1.6-4.8 mm Prod. No. 071318
4.0-12.0 mm Prod. No. 072766
Heat-shrinkable tubing set of 3 Prod. No. 075811
9 Soldering reflector nozzle* Prod. No. 074616
10 Reduction nozzle 14 mm* Prod. No. 070717
11 Reduction nozzle 9 mm* Prod. No. 070618
12 Fine dust filter Prod. No. 078218
13 HL-Scan Prod. No. 014919
14 Wide-slit nozzle* Prod. No. 074715
15 Feed roller Prod. No. 012311
16 Plastic welding rod*
Rigid PVC: Prod. No. 073114
HDPE: Prod. No. 071219
PP: Prod. No. 073411
ABS: Prod. No. 074210
17 Welding shoe* Prod. No. 070915
(* only for HL 1920 E and HL 2020 E)
(see page 160)
Declaration of Conformity
Manufacturer's warranty
T
his STEINEL product has been manufactured with great
care, tested for proper operation and safety in accordance
w
ith applicable regulations and then subjected to random
sample inspection. STEINEL guarantees that it is in perfect
condition and proper working order.
The product is guaranteed for 36 months or 600 hours of
operation commencing on the date of sale to the con-
s
umer. We will remedy defects caused by material flaws or
manufacturing faults. The warranty will be met by repair or
r
eplacement of defective parts at our own discretion. This
warranty does not cover damage to wearing parts, dam-
a
ge or defects caused by improper treatment or mainte-
nance nor does it cover breakage as a result of the prod-
uct being dropped. Further consequential damage to other
objects shall be excluded.
Claims under warranty shall only be accepted if the prod-
uct is sent fully assembled and well packed complete with
sales receipt or invoice (date of purchase and dealer's
stamp) to the appropriate Service Centre or handed in to
the dealer within the first 6 months.
Repair service:
If defects occur outside the warranty
period or are not covered by warranty,
ask your nearest service station for the
possibility of repair.
GB
2
20-230 V, 50/60 Hz
1600 W
1
2
2
40 450
3
00 500
–
–
No
II
–
Yes
≤ 70 dB(A)
≤ 2.5 m/s
2
/ K = 0.08 m/s
2
0.670 kg
H
L 1820 S
H
L 1620 S
Subject to technical modifications
V
oltage
Output
S
tage
A
irflow rate (l/min.)
T
emperature (°C)
Temperature setting
T
emperature display
Residual heat indicator
Protection class
(without earth terminal)
Thermostat
Thermal cut-out
Emission sound pressure level
Total vibration value
Weight
2
20-230 V, 50/60 Hz
1800 W
1
23
1
00 300 500
5
0 400 600
–
–
No
II
–
Yes
≤ 70 dB(A)
≤ 2.5 m/s
2
/ K = 0.08 m/s
2
0.800 kg
220-230 V, 50/60 Hz
2200 W
1 23
150 150 - 300 300 - 500
80 80 - 630
Infinitely variable in 10 °C steps via pushbutton
LCD
Yes
II
Yes
Yes
≤ 70 dB(A)
≤ 2.5 m/s
2
/ K = 0.08 m/s
2
0.880 kg
Technical specifications
HL 1920 E
HL 2020 E
Subject to technical modifications
Voltage
Output
Stage
Airflow rate (l/min.)
Temperature (°C)
Temperature setting
Temperature display
Residual heat indicator
Protection class
(without earth terminal)
Thermostat
Thermal cut-out
Emission sound pressure level
Total vibration value
Weight
220-230 V, 50/60 Hz
2000 W
123
150 150 - 300 300 - 500
80 80 - 600
Infinitely variable in 9 increments via setting dial
–
No
II
–
Yes
≤ 70 dB(A)
≤ 2.5 m/s
2
/ K = 0.08 m/s
2
0.840 kg
3
MANUFACTURER'S
YEAR
WARRANTY
M
Electrical and electronic equipment, accessories and pack-
aging must be recycled in an environmentally compatible
manner.
Do not dispose of electrical and electronic
equipment as domestic waste.
EU countries only:
Under the current European Directive on Waste Electrical
and Electronic Equipment and its implementation in national
law, electrical and electronic equipment no longer suitable
for use must be collected separately and recycled in an en-
vironmentally compatible manner.
Disposal
