09-254B 6 - 17 rev 1/00

PARTS section 6

Parts List for Figure 4

Ref Part No. Description Quantity

1 87-235 Shaft, Spindle 1

2 87-209843 Seal 2

3 87-244643 Bearing Cone 2

4 87-244610 Bearing Cup 2

5 87-240001-5 Casting, w/o breather hole 1

87-240001-6 Casting, with breather hole 1

7 87-203293 Retaining Ring 2

8 87-203815 Bolt, 3/8 x 1-1/2 SHCS 4

9 87-240101-01 Blade Adapter with Cup 1
