TMAX™ Owner’s Manual | Page 15
TMAX LP Mounting Kit - Chevy - PN 101363
PN 101363
01 13251 1BRKT BODY MNT FRONT RF PC BLACK
05 C1025 10CAP SCR 0.63-11X2.00 HHGR8
04 101790 2FRAME EXT 7.75X12.00
02 13254 1BRKT BODY MNT FRONT LF PC BLACK
06 C5902 28WASHER 0.63 SAE FLAT YELLOW GR8
07 24868 14NUT 0.63-11 HHGR8 NYLOC
08 109051 2SPACER FRONT C5500 2019
09 84053 4CAP SCR 0.63-11X2.25 HHGR8
ITEM PART No. QTY.DESCRIPTION
41.13 (12')
65.13 (14')
BODY MOUNT ON REAR
OF SUBFRAME.
BODY MOUNT ON FRONT OF SUBFRAME
1
2
9
9
5
5
5
5
5
5
5
4
8
6
6
6
7
4
CENTER OF AXLE
TO REAR OF
FRONT MOUNT
