TMAX™ Owner’s Manual
Light Box/Reflector Assembly
ITEM NO.
PART
NUMBER
DESCRIPTION QTY.
10 19338 BOX LIGHT ASM MOUNT LH PAINTED BLK 1
11 19337 BOX LIGHT ASM MOUNT RH PAINTED BLK 1
37 10334 GROMMET 4.00 ROUND LAMP (PETERSON) 4
38 13143 LIGHT STOP/TURN/TAIL 4 RND LED 2
219326 DEL PUKCAB THGIL626729*3
40 13145 LIGHT CLEARANCE RED RND 2 LED 7
41 C4862 GROMMET FOR 2 CLEARANCE 30700 7
42 2320 LICENSE PLATE LIGHT ROUND 430 W 2
21-FPB ELOH 00.1 CITSALP GULP0022234
44 17352 PLUG PLASTIC .375 HOLE BPF-3/8 2
1DP/OM 1XAMT MSA REZILIBATS3744574
4DER 00.3 ROTCELFER145084
2REBMA 00.3 ROTCELFER045094
50 56794 LIGHT CLEARANCE AMBER .75IN MCL-11AKB 2
*For 16K body, substitute PN 120577 - Stop-Tail-Turn-Reverse Light Combo
40
4848
49
50
41
A
37
43
40
41
44
39
10
40
41
38
37
