Page 42 | Stellar
®
TMAX™ Owner’s Manual
Mud Flap Assembly - PN 19494
ITEM PART DESCRIPTION QTY.
1 C4821 MUD FLAP 24.00X24.00 STELLAR 2
2 0485 CAP SCR 0.31-18X1.25 HHGR5 8
3 0342 NUT 0.31-18 HH NYLOC 8
5 8C2225 WASHER 0.31 FENDER 1.25OD
2
4
1
3
5
PN 19494
D06074 8WASHER 0.31 BONDED
