TMAX™ Owner’s Manual | Page 45
License Plate Hardware Assembly - PN 54548
ITEM PART DESCRIPTION QTY.
1 0654 NUT 0.25-20 WING 2
41047 22 WASHER 0.25 BONDED SEALING NEO BACK
3 0340 WASHER 0.25 USS FLAT ZINC 6
5 0333 NUT 0.25-20 HHGR5 NYLOC 2
6 0521 WASHER 0.25 LOCK 2
4 0437 CAP SCR 0.25-20X1.25 HHGR5 2
2
5
6
3
3
3
4
1
Compartment wall
between these washers.
PN 54548
