10. EXPLODED VIEW WITH PART LIST
POS PART NUMBER DESCRIPTION NUM
1 A021039-018-00 Upper handle assembly 1
1-1 A021039-019-00 Switch box assembly 1
1-1-1 A021039-007-00 Switch box lower cover 1
1-1-2 A021039-021-00 hook plate 1
1-1-3 8370-517801-01 switch dragline 1
1-1-4 8343-510801-02 Trigger hook 1
1-1-5 8042-660102-00 Switch 1
1-1-6 A021039-006-00 Switch box upper cover 1
1-1-7 8342-510505-00 Button spring 1
1-1-8 8312-519201-00 Swtich button 1
1-1-9 8208-519201-00 Seal ring 1
1-1-10 8183-519201-00 Button bottom plate 1
1-1-11 8NH-03D01 Nut 1
1-1-12 8183-510906-00 hook plate 1
1-1-13 8183-510902-02 guide board 1
1-1-14 8342-510903-00 torsional spring 1
1-1-15 8SJAD03-25 Screw 1
1-1-16 A021039-017-00 Support plate 1
1-1-17 8440-531711-00 Plug connecting wire assembly 1
1-1-18 A021039-008-00 Switch box x plate 1
1-1-19 8422-515901-00 Cable wire 1
1-2 A021039-002-00 Upper handle 1
1-3 A021039-011-00 Plate 1
1-4 A021039-003-00 Switch rod 1
1-5 8313-515701-00 Handle foam sleeve 1
1-6 A021039-010-00 Plate 1
1-7 A021039-009-00 handle plastic sleeve 1
1-8 8SNAB40-16B Cross head ange screw 9
2 8086-513001-00 Pin 4
3 8202-513001-00 Spacer 4
4 A021039-004-00 Lower handle 1
5 8206-513001-00 bolt 2
6 A021039-025-00 Lower handle 1
7 8371-513001-01 Tube plug 2
8 8003-513003-00 Quick release knob 4
9 8007-512001-00 Cable clip 2
10 8206-513002-00 screw 2
11 A021039-012-00 Adjusting tooth 2
12 8440-513005-00 grass box assembly 1
12-1 A021041-024-00 grass box support 1
12-2 8181-513001-01 Indicator 1
12-3 A021041-009-00 grass box upper cover 1
12-4 8440-512012-00 Grass bag handle assembly 1
12-6-1 8001-512002-00 Box handle upper cover 1
12-6-2 8020-512006-00 Box handle lower cover 1
12-6-3 8SJAB40-14Q screw 1
12-5 A021041-023-00 Collection bag 1
13 A021039-020-00 Rear wheel shaft assembly 1
13-1 A021039-015-00 Wheel cover 2
13-2 8121-511002-02 Rear wheel 2
13-3 8202-989101-00 corrugatedgasket 2
13-4 A021041-020-00 Wheel shaft assy. 1
13-5 8SQDD05-12D Bolt 2
13-6 8003-513002-00 Height adjustment handle 1
13-7 8NE-05D01 Nut 2
13-8 8CC-10B Ring 2
POS PART NUMBER DESCRIPTION NUM
14 8SNAB50-20D Screw 8
15 8202-513002-01 Fixing board 2
16 8440-513007-00 Upper cover assembly 1
16-1 8342-513001-01 Torsion spring 1
16-2 8081-514701-00 rear shaft 1
16-3 A021041-008-00 Rear cover 1
16-4 A021041-006-00 decorative cover 1
16-5 A021041-007-00 handle 1
16-6 A021041-005-00 housing upper cover 1
16-7 8206-000001-00 Screw 1
17 A021039-022-00 deck assembly 1
17-1 A021039-014-00 Fix teeth 1
17-2 A021041-003-00 deck bottom cover 1
17-3 A021041-002-00 Deck 1
17-4 A021039-013-00 Fix teeth 1
17-5 8SNAB50-20D Screw 8
17-6 A021041-014-00 comb plate 1
17-7 A021041-015-00 comb plate 1
18 A021041-019-00 blade 1
19 8334-513002-00 Output sleeve 1
20 8304-511101-00 Blade positioning plate 1
21 8202-919003-00 Blade xing board 1
22 8206-511001-01 Bolt 1
23 8301-513001-00 Ballast 1
24 8SNAB40-16Q screw 3
25 A021041-004-00 housing front cover 1
26 A021039-023-00 Front wheel assembly 1
26-1 8324-436104-00 Friction gasket 1
26-2 8091-940202-00 Pin 1
26-3 A021041-010-00 Nut 1
26-4 8206-000001-00 Screw 3
26-5 A021041-012-00 front wheel right cover 1
26-6 A021041-017-00 support plate assembly 1
26-7 A021041-013-00 front wheel left cover 1
26-8 A021041-018-00 Bolt 1
27 A021041-028-00 Motor assembly 1
27-1 A021041-029-00 Motor assembly 1
27-2 8CC-08B Axis with circlips 1
27-3 8BC-220807-SS03 ball bearing 1
27-4 8440-513009-00 Electromagnetic component 1
27-5 8292-511004-02 Motor bracket 1
27-6 8SNAB50-20D Screw 3
27-7 8181-511010-00 spring pressure plate 3
27-8 8345-511001-01 brake pad 1
27-9 8SNAB40-08D Screw 6
27-10 8321-511001-00 brake block 3
27-11 8342-511901-00 spring 3
27-12 8122-511001-00 Big belt wheel 1
27-13 8BC-321509-SS23 bearing 1
27-14 8292-511005-00 brake disc 1
27-15 8BC-351710-SS02 bearing 1
27-16 8345-511002-00 belt 1
27-17 A021041-016-00 Motor holder 1
27-18 239-0006 Male terminal 1
27-19 233-1006 heat-shrinkabletube 0.06
28 A021041-037-00 Sponge 2
