StetSom SX2 - Page 2

2 3
General Descripon
Programming Rod
Antenna
LED Indicator
Infrared Transmier (3m)
Power Cable (50cm)
Infrared Receiver
Synchronizaon Key (SYNC/RESET)
Learning Key (LRN)
14
15
16
17
18
19
20
21
14
17
15
18
19
20
21
16
+12V (BLACK
AND WHITE)
GND (BLACK)
Introducon
The SX2 Alcance Control was developed to for long distance control
of automove or residenal audio and video whit up to 16 funcons
equipment. Due to its radio frequency (RF) technology, equipament can be
controlled at up to 500m in open target area.
Transmission is enhanced by FSK reducing external interference. Encrypted
rolling code prevents cloning technologies.
General Descripon
LED Indicator
Power
Forward ()
Rewind ()
Up ()
Down ()
Volume (+)
Volume (-)
Play/Pause
2nd (Enables the 2nd
Funcon)
Strap Neck Lanyard
Protecve Holster
Lanyard
1
2
3
4
5
6
7
8
9
10
11
12
13
2
3
4
5
6
7
8
9
10
11
12
13
1
