ELECTRICAL SYSTEM
Page ELECTRICAL SYSTEM - 60 Z001019/0_6_July 2008
SERVICE MANUAL MARINE ENGINES
6 Cyl. Wiring harness instrument panel (if alternator "PRESTOLITE" is
used - old version)
Designat. Component Description
F9 fuse
J1 23-pin plug connection engine cable - instrument cable
S1 switch ignition
S7 switch fix-n (speed-selector switch optional)
K10 relay charge control (90A PRESTOLITE)
L1 lamp charge control
L2 lamp cel - check engine lamp
L3 lamp oil pressure / pre-heating control
P1 gauge coolant
P2 gauge oil pressure (optional)
P3 gauge tachometer with running-time meter
P4 gauge trim (optional)
H22 warning horn
XS8 1-pin plug to lighting switch - instrument panel
XS9 2-pin plug charging control/relay charging control (wiring harness side)
XS10 2-pin plug charging control/relay charging control (instrument side)
X1/S1 4-pin plug ignition
X2/L1 10-pin plug charge control lamp
X3/L2 10-pin plug cel - check engine lamp
X4/L3 10-pin plug oil pressure warning lamp
X5/E10 2-pin plug lighting coolant display
X6/P1 3-pin plug coolant temperature gauge
X7/E11 2-pin plug lighting oil pressure
X8/P2 3-pin plug oil pressure gauge
X9/S7 10-pin plug speed-selector switch (optional)
X11/P3/E12
8-pin plug speed instrument / lighting speed instrument
X12/E13 2-pin plug lighting trim (optional)
X22/P4 3-pin plug trim (optional)
