Stiga 13-6104-21 User Manual

Edition Manual Chapter Page
2014-09-20 Workshop Manual, GGP Park 4 Hydraulic system 4
The power transmission and the hydraulic assisted steering and implement lifter work with
the same oil, but in two separate parallel systems. Therefore, the descriptions are divided
in the following headings:
The following sections will explane the physical arrangement of the hydraulic components
and give a functional description.
Art.
Number
Machine
2 Wheel drive 4 Wheel drive Hydraulic pump in the rear axle drive See "4.3" at page 5 Separate hydraulic pump See "4.4" at page 8 Hydraulic steering, 4WD See "" at page 11 Hydraulic steering, 2WD See "4.6" at page 18 Hydraulic implement lifter See "" at page 11
13-6269-XX Park Pro 18 4WD X X X X
13-6270-XX Park Pro 21 4WD X X X X
13-6271-XX Park Pro 16 4WD X X X
13-6272-XX Park Pro Svan 4WD X X X X
13-6273-XX Park Pro 20 4WD X X X X
13-6274-16 Park Pro 23 4WD X X X X
13-6275-16 Park Pro Silver X X
13-6276-XX Park Pro 25 4WD X X X X
13-6310-XX Park Excellent 16, 620 W X X
13-6311-XX Park Plus X X
13-6312-XX Park Royal 4WD X X X
13-6313-11 Park Excellent X X
13-6314-11 Park Plus Unlimited X X
13-6317-32 Park 740 PWX X X X
13-6318-31 Park 520 DP X X X
13-6319-31 Park 520 DPX X X X
13-6320-11 Park 520 Anniversary X X X
13-6372-11 Park Power 16 4WD X X
13-6373-XX Park 740 WX, Park Ro. 4WD X X X
13-6374-11 Park Champion 4WD X X X
13-6375-11 Park Power 4WD X X
13-6377-11 Park Prestige 4WD X X
13-6378-XX Park Residence 4WD X X X
13-6379-XX Park Ranger Svan X X X
13-6380-XX Park 620 PW X X X
13-6381-XX Park 540 LPX X X X
13-6384-11 Park 123 X X
13-6384-12 Park 420 LM X X
