2014-09-09 Workshop Manual, GGP Park 6 Control wires 1
6 Control Wires
Contents in this chapter
General
All the manoeuvring functions are incorporated on the control panel. This is an excellent
solution in terms of ergonomics and comfort. It also simplifies the service work since all the
controls and adjustments can be accessed in one place.
All mechanical control movements from the operator to the respective device on the ma-
chine are conducted by wires and in some cases with rods.
These equipments are mainly the same for all the machines covered by this manual, but
in some cases configurated in different ways. Where divergences occour between the
machines, particular instructions are given for each particular equipment.
This chapter gives a brief description of the equipments and describes their repair and re-
placements.
6.6 Brake/clutch .............................. 14
6.6.1 Senator .................................. 14
6.6.2 President, Royal, Pro 16,
Pro 20, Pro Diesel.................. 17
6.7 Replacement of PTO wire......... 19
6.7.1 Machines with the control
panel to the right.................... 19
6.7.2 Compact ................................ 20
6.7.3 Adj. of PTO wire and brake.... 21
6.8 Differential lock wire................. 24
6.8.1 Replacement.......................... 24
6.8.2 Adjustment............................. 25
6.1 Description.................................2
6.2 General measures .....................3
6.2.1 Elbow links .............................3
6.2.2 Cable holders .........................4
6.3 Gearshift wire.............................5
6.3.1 Replacement ..........................5
6.3.2 Adjustment .............................6
6.4 HST control wire (2WD+4WD)...7
6.4.1 Replacement ..........................7
6.4.2 Adjustment (2WD)..................9
6.5 HST ctrl. wire (4WD ext. pump) 1
6.5.1 Replacement ..........................11
6.5.2 Adjustment (4WD ext. pump) .12
