Stihl FS 100 RX Spare Parts

Illustration H
FS 100, FS 100 R, FS 110, FS 110 R, FS 110 X, FS 110 RX, FS 100 RX 25
Vergaser C1Q-S81 Carburetor C1Q-S81 Carburateur C1Q-S81
Bild-
Nr.
Teile-Nr. St.-
Zahl
Benennung Part Name Désignation
(41.2003) (41.2003) (41.2003)
31 ✻ 4119 122 3002 1 Feder Spring Ressort
32 ✻ 4229 121 2701 2 Kappe Cap Capuchon
33 ✻ 4180 121 0801 1 Abschlussdeckel End cover Couvercle
34 ✻ 4180 121 3000 1 Startwelle Choke shaft Axe de volet de démarrage
35 ✻ 4180 121 4801 1 Pumpenmembrane Pump diaphragm Membrane de pompe
36 ✻ 4180 129 0903 1 Dichtung Gasket Joint
37 ✻ 4180 121 8600 1 Scheibe Washer Rondelle
38 ✻ 4180 122 3001 1 Feder Spring Ressort
39 ✻ 4180 121 5800 1 Pumpenkolben Pump piston Piston de pompe
40 ✻ 1132 122 3600 1 Dichtring Sealing ring Anneau de joint
41 ✻ 4180 122 3002 1 Feder Spring Ressort
42 ✻ 1120 121 7801 1 Sieb Strainer Tamis
43 ✻ 4137 121 5603 1 Festdüse0.34 Fixed jet0.34 Gicleur fixe0.34
✻ 4180 007 1060 1 Satz Vergaserteile
)
9, 10, 18, 19, 35, 36
Set of carburetor parts
)
9, 10, 18, 19, 35, 36
Jeu de pièces de carburateur
)
9, 10, 18, 19, 35, 36
(1)FS100, (2)FS110, (3)FS110X, (4)FS100R, (5)FS110R, (6)FS110RX,
(7)FS100RX
