Stihl FS 100 RX Spare Parts

Illustration K
FS 100, FS 100 R, FS 110, FS 110 R, FS 110 X, FS 110 RX, FS 100 RX 31
Handgriff Handle Poignée
Bild-
Nr.
Teile-Nr. St.-
Zahl
Benennung Part Name Désignation
4137 790 1307 1 Bedienungsgriff (4,5,6,7)
)
1-12
Control handle (4,5,6,7)
)
1-12
Poignée de commande
(4,5,6,7)
)
1-12
1 4137 790 0300 1 Handgriff (4,5,6,7) Handle (4,5,6,7) Poignée (4,5,6,7)
2 4137 791 9400 2 Spannschelle (4,5,6,7) Hose clamp (4,5,6,7) Collier de serrage (4,5,6,7)
3 9022 341 0960 2 Schraube IS-M5x12-10.9
(4,5,6,7)
Spline screw IS-M5x12
(4,5,6,7)
Vis cylindrique IS-M5x12
(4,5,6,7)
4 4137 182 4505 1 Schenkelfeder (4,5,6,7) Torsion spring (4,5,6,7) Ressort coudé (4,5,6,7)
5 4137 182 1701 1 Kombischieber (4,5,6,7) Slide control (4,5,6,7) Curseur combiné (4,5,6,7)
6 4137 182 1001 1 Gashebel (4,5,6,7) Throttle trigger (4,5,6,7) Manette des gaz (4,5,6,7)
7 4137 182 4504 1 Schenkelfeder (4,5,6,7) Torsion spring (4,5,6,7) Ressort coudé (4,5,6,7)
8 4137 182 0802 1 Sperrhebel (4,5,6,7) Trigger interlock (4,5,6,7) Levier d'arrêt (4,5,6,7)
9 4128 182 4501 1 Schenkelfeder (4,5,6,7) Torsion spring (4,5,6,7) Ressort coudé (4,5,6,7)
10 4128 793 3000 1 Schieber (4,5,6,7) Slide (4,5,6,7) Curseur (4,5,6,7)
11 4128 791 3100 1 Feder (4,5,6,7) Spring (4,5,6,7) Ressort (4,5,6,7)
12 9074 478 3025 4 Schraube IS-P4x16 (4,5,6,7) Pan head self-tapping screw
IS-P4x16 (4,5,6,7)
Vis cylindrique IS-P4x16
(4,5,6,7)
13 4180 180 1100 1 Gaszug (4,5,6,7) Throttle cable (4,5,6,7) Câble de commande des gaz
(4,5,6,7)
14 4130 790 1316 1 Rundumgriff (4,5,6)
)
15-17
Loop handle (4,5,6)
)
15-17
Poignée circulaire (4,5,6)
)
15-17
15 4123 791 7400 2 Lasche (4,5,6) Clamp (4,5,6) Bride de fixation (4,5,6)
16 9022 341 1350 2 Schraube IS-M6x25-10.9
(4,5,6)
Spline screw IS-M6x25 (4,5,6) Vis cylindrique IS-M6x25
(4,5,6)
17 9222 068 0900 2 Mutter DIN557-M6-5 (4,5,6) Square nut M6 (4,5,6) Ecrou à quatre pans M6
(4,5,6)
18 4130 791 4400 1 Bügel (4,5,6) Barrier bar (4,5,6) Etrier (4,5,6)
19 4180 790 3402 1 Rundumgriff (7)
)
20 - 22
Loop handle (7)
)
20 - 22
Poignée circulaire (7)
)
20 - 22
20 4137 791 9400 1 Spannschelle (7) Hose clamp (7) Collier de serrage (7)
21 9291 021 0120 1 Scheibe DIN125-A5,3 (7) Washer5.3 (7) Rondelle5,3 (7)
22 9022 313 1030 1 Schraube IS-M5x23-8.8 (7) Spline screw IS-M5x23 (7) Vis cylindrique IS-M5x23 (7)
(1)FS100, (2)FS110, (3)FS110X, (4)FS100R, (5)FS110R, (6)FS110RX,
(7)FS100RX
