MS 441 C-M
English
35
Locking chain with chain brake
– in an emergency
– when starting
– at idling speed
The chain is stopped and locked when
the hand guard is pushed toward the bar
nose by the left hand – or when brake is
activated by inertia in certain kickback
situations.
Releasing the chain brake
N Pull the hand guard back toward the
front handle.
NOTICE
Always disengage chain brake before
accelerating engine and before starting
cutting work. The only exception to this
rule is when you check operation of the
chain brake.
High revs with the chain brake engaged
(chain locked) will quickly damage the
powerhead and chain drive (clutch,
chain brake).
The chain brake is designed to be
activated also by the inertia of the front
hand guard
if the forces are sufficiently high. The
hand guard is accelerated toward the
bar nose - even if your left hand is not
behind the hand guard, e.g. during a
felling cut. The chain brake will operate
only if it has been properly maintained
and the hand guard has not been
modified in any way.
Check operation of chain brake
Before starting work: Run engine at idle
speed, engage the chain brake (push
hand guard toward bar nose).
Accelerate up to full throttle for no more
than 3 seconds – the chain must not
rotate. The hand guard must be free
from dirt and move freely.
Chain brake maintenance
The chain brake is subject to normal
wear. It is necessary to have it serviced
and maintained regularly by trained
personnel, such as your STIHL servicing
dealer, at the following intervals:
Chain Brake
143BA011 KN
143BA012 KN
Full-time usage: every 3
months
Part-time usage: every 6
months
Occasional usage: every 12
months

Stihl MS 441 C-M Specifications

General

Motor type	2-stroke motor
Chain gauge	1.3 mm
Chain pitch	3/8 \
Automatic oiling	Yes
Oil tank capacity	0.36 L
Fuel tank capacity	0.725 L
Engine displacement	70.7 cm³
Engine power	5.6 hp
Power source	Gasoline

Weight and Dimensions

Weight	6600 g
