10 - English
INSTALLATION
Carefully feed the fan’s electrical wiring through the
canopy screw cover ring and canopy, then install the
cover ring and canopy on the downrod as shown.
NOTE: Make sure the notched openings on the rim of the
canopy screw cover ring are facing up.
CANOPY
CANOPY SCREW
COVER RING
NOTCHED
OPENINGS
This step is needed only if you are installing your
ceiling fan using an extension downrod (not pro-
vided) and have installed the center arm support
from the previous step. If you are using the down-
rod provided in this package, or if you are using
an extension downrod but chose not to install the
center arm support, skip this step and proceed
directly to installing the canopy screw cover ring
and canopy.
Carefully feed the fan’s electrical wiring through the
center arm support cover, then install the support with
the cupped side facing down.
CUP SIDE DOWN
ARM
SUPPORT COVER
