Still STEDS R70-16 User Manual

02
Steer axle
1
Contents Page
Technical Data for 1
Maintenance Service
Mechanical configuration of Steer axle
Steer axle removal 2
Steer axle installation 2
Wheel hub - Removal and 3
Dismantling
Wheel hub - Reassembling and 3
Installation
Wheel angle stop adjustment 4
Checking the steering angles 4
Stub axle - Removal and 5
Dismantling
Stub axle - Reassembling and 6
Installation
Lubricating the steer axle with 6
grease
Track rod removal 7
Track rod installation 7
Steer cylinder removal 8
Steer cylinder installation 8
Workshop Manual 7052/56/74-76, 7054/58/77-79
