MODEL: STR-BGC PRODUCT CODE: 60165 06/2018
Installation (Cont.)
Gas adjustment (conversion for use with LPG)
This cooktop is tted out for use with Natural Gas (NG). If it is to be used with
liqueed petroleum gas (LPG), the gas regulator valve and the burners have
to be converted.
IMPORTANT: Before starting the conversion, make sure all gas is
switched off (and preferably disconnected from the appliance) and the
electrical power has been disconnected.
• Remove the trivets, burners, burner crowns and caps (Fig. 10-A).
• Unscrew the injector (Fig. 10-B) and replace it with the stipulated injector
for the new gas supply (see the Table 1 on next page).
Fig. 10-A Fig. 10-B
Fig. 9-A
Fig. 9-B
Fig. 9-C Fig. 9-D
Factory-set state
