Product Overview (Cont.)
NOTE: Due to continued product improvement, images and illustrations in this manual
may vary slightly from the product purchased. All images in this manual are for
reference purposes only. Parts are not necessarily pictured to scale.
Rear view
8 Rear housing
9 Exhaust vent connection
10 Ventilation slots
11 Power cord and plug
12 Adjustable feet (4)
13 Exhaust vent
Installation hardware
14 Hanging brackets (2)
15 M6x60mm expansion bolts (4) (for solid walls)
16 Plastic spacers (2)
Also supplied but not shown:
Small screws (3) (for vent installation)
Extra control panel print (for upside down use)
6x50mm screws 10mmØ & plugs (for timber studs)
13
10
9
8
11
Documentation (not shown)
Instruction manual
Quick start guide
Warranty certificate
14
15
16
12
