Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
A
Tools reqiured
1cm 2
3
4
56
7
8910
11 12
13
14
15
16
1 inch
2
3
4
56
Rulers - Use this ruler to help correctly identify the screws
Philips screwdriver (medium)
Flathead screwdriver (medium)
Allen key (incl)
Small hammer
Dowel Ø8x40 x34
Conformat screw Ø7x 60mm x20
Screw 3.5 x 35mm x60
Barrel nut Ø10 x 14mm x24
Allen key 4mm x1
Cover cap Ø15/Ø18 x12
Cover cap Ø8/Ø13 x16
E F
H K L
N P
Spacer 20x72x3mm x2
3
Rubber hammer
Q
Connecting bolt M6 x 50mm x5
Connecting bolt M6 x 75mm x19
R
Metal dowel x16
S
Locking nut x32
T
Cover cap Ø4/Ø17 x12
U
Cover cap Ø10/Ø13 x6
V
Cover cap Ø12/Ø3 x20
Y
Rubber hammer
Rubber hammer
A
8x40 Wooden dowel x 47
B
M6x10x13 Cross dowel x 4
C
M6x75 Bolt x 4
G
7x60 Screw x 4
H
D=35 Sector x 4
I
3,5x40 Screw x 30
N
D15x18 Cover Cap x 9
R
4mm Allen key x 1
D
6,3x70 Screw x 5
E
55/12,5x5(Zn) x 4
F
7x50 Screw x 20
J
D4x13 Cover Cap x 20
K
D8x13 Cover Cap x 11
O
D35 Cover Cap x 4
M
Glue x 1
L
D15x18 Cover Cap x 4
S
D15x12 Locking nut x 4
P
7x34 Metal dowel x 4
Q
5x38 (Zn) Screw x 1
