- 22 -
MAINTENANCE
RP652
Stop filling when:
A distinct clicking noise is heard in the
exciter while shifting the lever.
You no longer feel a cushion of air when
moving the throttle lever.
Attention - When filling, the circuit path is
shortened.
1. To check oil level, start the engine and bring
up to operating speed.
2. Move throttle lever several times backward
and forwards between V and R.
3. The correct oil level should be somewhere in
the area shown (see illustration). At this
point, the throttle lever must be in the V
position.
4. If the level is too low, top off with hydraulic
fluid. If too high, drain off excess fluid.
5. With the machine running and the throttle
lever in the V position, close locking
screw (1).
