- 33 -
PARTS LIST
ITEM PART NO. DESCRIPTION QUANTITY DIN
1 63332 Venting Screw 1 -
2 63333 V-Belt Pulley 1 -
3 62203 V-Ring 1 -
4 61313 Rotary Shaft Seal 1 -
5 61574 Retaining Ring J90 x 3 V 1 -
6 61572 O-Ring OR 80 x 3.5 1 -
7 63334 Sealing Flange 1 -
8 63335 Tolerance Ring 1 -
9 62207 Internal Ring 1 -
10 63336 Cylindrical Roller Bearing 4 -
11 61337 O-Ring OR 27 x 2.5 1 -
12 63337 Exciter Housing 1 -
13 61563 Screw Plug M14 x 1.5 5.8 1 910
14 60146 Copper Gasket A14 x 18 1 7603
15* 62214 SHCS M10 x 25 10.9 4 912
16 63338 Eccentric Weight 4 -
17 63339 Set Pin 8m6 x 55 1 6325
18 63340 Exciter Shaft 1 -
19 60590 Retaining Ring A45 x 1.75 2 471
20 63341 Deep Groove Ball Bearing 1 -
21 63342 Gear Wheel 1 -
22 63343 Guidance 1 -
23 62218 Retaining Ring A6 x 0.7 1 471
24^ 62219 Deep Groove Ball Bearing 2 -
25 62220 Retaining Ring J19 x 1 1 472
26 62221 Piston 1 -
27 62222 Piston Packing 1 -
28 63344 O-Ring OR 68 x 3 3 -
29 63345 Bearing Cover 1 -
30 61639 Fitting 1 -
31 60631 SHCS M6 x 16 8.8 4 912
32 60402 Lock Washer VS 6 4 -
33 60490 Retaining Ring J80 x 2.5 2 472
34 63346 Sealing Flange 2 -
35 63347 Gear Wheel 1 -
36 63348 Key A 14 x 9 x 40 1 6885
37 63349 Exciter Shaft 1 -
Eccentric Assembly
* Loctite 640
^ Shell Alvania R3 Grease
To Next Page
