Storage Canopy C4040 - Parts List

2
Parts List
Part Code
Description
Qty
1
Base plates for winch door
2
2
Side base plates
2
2A
Lower standing leg at left
2
3L
Bottom standing leg for front endwall at left
3
3R
Bottom middle standing leg for front endwall at right
1
4
Top middle standing leg for front endwall
2
5
Top side standing leg for front endwall
2
6L
Bottom door post at left
1
6R
Bottom door post at right
1
7
Middle door post
2
8
Top door post
2
9
Door beam
2
9A
Door boom
1
10
Horizontal tube for front endwall
6
10A
Horizontal tube for front endwall shoulder
2
11
Square tube for winch door
1
12
Mechanical wheel with wire rope
1
13
Bottom tension tube for front endwall
4
14
Clips
6
14A
Welded metal plate
2
14B
Single hole angle iron
1
15
The front door vertical tube
9 Groups
16
Stake peg
12
17
Splint iron
12
18
Carriage Bolts M10*90
24
19
Bolts M10*90
62
20
Carriage Bolts M12*100
8
21
Bolts M10*30
2
