Feed fitting kit for WAMAB, Item No. 61 20 01
Is used for the optimum installation of the water feed for operating the WAMAB with a STORCH separating system.
Two water inlets are mounted on an assembly plate here, one for connecting to fresh water and one for connecting to
the circuit water of the separating system as well as two water outlets. The spray kit and a high-pressure cleaner (e.g.,
for operation with Turbo-Wash) can be connected. When operating the two ball valves, the water feed can be set to
fresh or circuit water and can be forwarded to the spray kit or the high-pressure cleaner.
Turbo-Wash for WAMAB, Item No. 61 20 50
Paint roller cleaner for fixed installation to the WAMAB and for connecting to
a high-pressure cleaner. The water consumption per paint roller sinks to 7 litres
and the cleaning time is less than 1 minute. The rollers are subsequently spun
due to the high speed of the rollers during cleaning and come out of the device
almost dry. Robust professional device, rust-proof.
Designation Item No.
Drain fitting 70 mm, 1 1/2” 61 20 14
Ball chain for the drain plug 61 20 15
Screw cover 92, top left 61 20 29
Screw cap 50, with seal 61 20 30
Sealing plug for the sedimentation vessel 61 20 32
Filling level display with seal 61 20 35
Seal settling tank / wash basin 61 20 36
Drain cock 3/4”, bottom left 61 20 37
Three-pin earthed plug for immersion pump 65 77 16
Wash area for pasting machines 61 20 20
Designation Item No.
Wash basin, small 61 20 21
Spray head 61 20 11
Reduction 1/2” male thread
x 3/4” female thread
60 63 31
Spray hose 61 20 13
Spray holder 61 20 46
Screw support 92, threaded 61 20 22
Screw cap 92, drilled 61 20 42
Siphon 61 20 43
Transition hose piece 61 20 12
Siphon paste drain 61 20 06
Rubber tensioning strap set for WAMAB 61 20 25
4. Spare parts
Translation of the original instruction
