USER MANUAL
WWW.STRANDLIGHTING.COM
VISION.NET HARDWARE
11
3
VISION.NET DIN RAIL
ENCLOSURES
443581626885 rev A 4/19/22
1
VISION.NET DIN RAIL
ENCLOSURE
OVERVIEW
PRODUCT NAME ORDER CODE
Vision.Net DIN Rail Enclosure - Small 53906-001
INSTALLATION AND SET UP
To prepare the Vision.Net DIN Rail Enclosure for installation:
Step 1. Place enclosure on a fl at surface.
Step 2. To remove cover, use a #2 Philips screwdriver to remove the screws from the bottom of the cover, and
loosen the upper screws. Slide cover upwards to disengage keyhole mounts.
Step 3. Remove accessories from the enclosure.
Step 4. Determine appropriate knockouts and mounting holes to use for your specifi c application. If grounding
the enclosure, note the desired orientation of the ground stud prior to removing knockouts.
Step 5. To remove a knockout, position the tip of a fl at head screwdriver against the stamped edge and pressing
down sharply and tapping the screwdriver with a hammer. Once the knockout is dislodged use a pair of
pliers to grab the knockout, twisting back and forth until the attachment points snap. Repeat as needed.
MOUNTING
The enclosure must be mounted using at least four points of contact. If installed below grade to an exterior wall take
care to install a vapor barrier between enclosure and wall to avoid rusting of enclosure.
To surface mount the Vision.Net DIN Rail Enclosure:
Step 1. Prepare surface as needed for mounting of enclosure. Mark locations on surface for the four mounting
holes located on the rear of the enclosure.
Step 2. Mount enclosure using 5/16” rounded head fasteners. If mounting to a hollow wall, concrete or block use
appropriate anchors where required.
To fl ush mount the Vision.Net DIN Rail Enclosure:
Step 1. Prepare surface as needed for mounting. Mark locations in wall cavity for the four mounting holes
located on the left and right side of the enclosure.
Step 2. Mount enclosure using 1/4” rounded head fasteners or similar. If mounting to a hollow wall, concrete
or block use appropriate anchors where required.
VOLTAGE BARRIER INSTALLATION
To install voltage barriers for the Vision.Net DIN Rail Enclosure (if required):
Step 1. Determine placement of voltage barriers. The small enclosure includes two static horizontal, and one
adjustable vertical barriers and the large enclosure includes three static horizontal, and three adjustable
vertical barriers that mounts on the DIN rail.
Step 2. Install required horizontal barriers by removing and reinstalling the corresponding #2 Phillips head
screws.
Step 3. Install the vertical barriers to the desired DIN rail. Barriers can be adjusted after installation of DIN
devices and secured in place by tightening the #2 Phillips head screw. Do not over-tighten.
Step 4. To protect wiring from abrasion, install edge grommet on barriers. Cut the required length of grommet
and press into the notches of the barrier.
