USER MANUAL
WWW.STRANDLIGHTING.COM
VISION.NET HARDWARE
17
WIRING
Ceiling Occupancy Sensors should be connected to a Vision.Net station.
To connect wiring to ceiling occupancy sensors:
Step 1. If conduit is required by local code, route low voltage wiring into adjacent junction box and secure
with included 1/2- inch nipple.
Step 2. Connect low voltage network to Interface Board with (4) #18 AWG (.75 mm2) wires according to the
wiring diagram below.
Note: Up to eight (8) Occupancy Sensors may be linked in parallel.
