STRATCO OUTBACK
®
FLAT ATTACHED INSTALLATION GUIDE
GUTTER FRONT
0mm
50 60 70 80 9040302010
100mm
FOLD FOLD
FOLD
FOLD FOLD FOLD
20mm 58mm 80mm
110mm 24mm
EDGE 160 135° EXTERNAL MITRE FLAT PATTERN TEMPLATE (A)
CUTOUT TEMPLATE FOR MARKINGUP GUTTERS
FLIP TEMPLATE FOR LEFT & RIGHT VARIATIONS
ENSURE TEMPLATES ARE PRINTED AT “ACTUAL SIZE”
PAIR BELOW TEMPLATE 135° EXTERNAL A WITH 135° EXTERNAL B SEE OVER
135° EXTERNAL PAGE 1
