Stratus SRC25 - EXPLODED VIEWS & PARTS (SRC50 & SRC502)

7
EXPLODED VIEWS & PARTS
SRC50&SRC502:
# Description
1 Body***
2 Fan Cover
3 Head Screws
4 Head
5 HeadO-ring
†
6 Motor Bolts***
7 Bearing***
8 CylinderO-ring
†
9 Set Screw
10 Fan
11 Pipe Plug
13 Valve Plate
††
14 LeafValve
††
15 ValveLimiter
††
16 Valve Screw
††
17 LeafValve
††
18 Valve Screw
††
19 Valve Retainer
††
20 Plug
22 Bearing***
23 Cup
†
24 Retainer Plate***
25 Eccentric
26 Rod
27 Cylinder
†
28 Retainer Screw
†
29 Motor***
30 Fan
***Not available for purchase
†
ItemsincludedinrepairkitSRC50K
††
ItemsincludedwithSRC50VPassembly
