6 - 6#32 thumbscrews x 6
5 - Main body
8 - Pushpin standoff x 8
4 - Kensington lock
7 - Foot mounting hole x 4
13 - Bracket x 4
3 - Drive slots x 2
14 - Foot x 2
12 - Left/Right bracket mounting point x 4
9 - Integrated carry handle
11 - M3 thumbscrews x 6
BC1 Overview
2 - PCI thumbscrew & nut x 4
1 - Top/Bottom bracket mounting point x 8
10 - Threaded standoff x 8
BC1 Specification
Width - 260mm
Assembled height - 115mm
Weight - 1.82Kg
Length - 370mm
PSU support - ATX 12V / BTX, ATX large and ATX-EPS
Thickness - 8mm
Table material - AL5052
Screw material - SS304
Drive support - Up to 2 x 2.5" or 2 x 3.5"
Motherboard support - XL, E, Mini, & Micro- ATX, Mini ITX
Max total load capacity - 25Kg
Motherboard standoff height - 25mm
Bracket cooling support - 240, 140, 120, 92, 80 mm
PSU max weight - 10Kg
Max bracket weight - 5Kg
8
6
7
14
2
9
10
1113
1
12
5
3
4
