Key Features
1.... L Channel Vacuum Tubes 4.... Input Jacks 7.... AC Power Socket
2.... Volume Control 5.... R Channel Output Jacks 8.... Fuse Holder
3.... R Channel Vacuum Tubes 6.... L Channel Output Jacks 9.... Power Switch
2
Specification
Valve Tube Model 6F3
Power Output 2.5W + 2.5W @ 8 Ohms
Frequency Response 800Mv
Residual Noise < 0.6 mV AC
Input Voltage 100 - 240V AC Standard IEC Jack with fuse protection (2A)
Power Consumption 33W
Input Impedance 10K Ohms
Output Impedance 16/8/6/4 Ohms
Dimensions 132 × 96 × 100mm (W×D×H)
Input Connector Type RCA Jacks
Output Connector Type Banana Jacks
Weight 1.7Kg
OVERVIEW - P3
1
3
7 8 965
4
