Warning
• Please do not begin installation until you have thoroughly read and understood these instructions.
• Failure to read, thoroughly understand, and follow all instructions may result in serious personal
injury, property damage, or death. It is the installer’s responsibility to ensure all mounting systems
are properly assembled and installed using the instructions provided.
• Installation by a qualified professional is highly recommend for this product. Do not install if you
have doubts regarding the eectiveness or safety of an installation method.
• This product is intended for indoor use only. Use of this product outdoors may lead to product
failure or personal injury. For support please call Customer Care at 866.424.4489.
• Do not install if any parts are missing or defective. Do not attempt to replace with unapproved
parts or materials or install without all required parts.
• Before installing, ensure the supporting surface will support the combined load of the equipment
and hardware, including ensuring that the wall that you plan to use will safely support four times
the combined weight of the mount and your chosen display configuration.
• Use of a suitable safety cables is recommended as a redundant safety measure, and may be
required under local building codes.
• Always use an assistant or mechanical lifting equipment to safely lift and position the equipment.
• Screws must be tightly secured. Do not overtighten screws or damage may occur and product
may fail.
• Under no circumstance should this product be mounted to metal studs.
• The manufacturer does not accept responsibility for incorrect installation.
• Do not exceed the maximum load (see next page).
Preparation Is Key
Every installation is dierent, so the modular digital display mount provides a system that is entirely
customizable to your needs. Because your install is unique, this manual addresses assembly
instructions, but does not address how to select the hardware you need.
To plan the install, visit the Snap One website and visit the Modular Digital Display Mount product
page. There you’ll find an online planning tool. You tell us how many TVs you have, what their sizes
and weights are, and a few other key details, and we’ll provide you with a plan for your install.
Ensure that you purchase enough gear to hold your displays safely and securely!
Tools Required
• Concrete anchors (if needed)
• Masonry bit per anchor bolt instructions
• Power drill
• Drill bit,
3
/16” (5mm)
• Hex wrench / bit, 3mm
• Hex wrench / bit, 6mm
• Phillips screwdriver
