5
Utility Boxes
SM-CB-CM-D
Hex key 3mm×53mm
SM-CB-CM-S
Hex key 3mm×53mm
Arms
SM-CB-LARM / SM-CB-PARM
Screw M5×14 Screw M6×14 Screw M6×30 Screw M8×30 Screw M8×50
Double hole washer Plastic spacer 15×8×5 Plastic spacer 15×8×15
Hex key 6mm×120mm
