Stryker Isolibrium 2971 Maintenance Manual

F
FFiigguurree 1199 –– GGeell ccrriibb
12.Remove the two purse lock wire tie (M)(Figure 20). Save the purse lock wire ties.
FFiigguurree 2200 –– PPuurrssee lloocckk wwiirree ttiiee
13.Disconnect the LAL fan from the quick connection.
14.Remove the LAL fan from the LAL fan nest and discard the LAL fan (J) (Figure 21).
NNoottee -- During reinstall, route the cable back through the foam and make sure that the new fan is seated into the LAL fan
nest.
2971-009-002 Rev D.0 43 EN
