Stryker MV3 5900 User Manual

A
B
C
FFiigguurree 2211 –– TTwwoo--ssttaaggee IIVV ppoollee
AAttttaacchhiinngg oorr rreemmoovviinngg tthhee ppaattiieenntt hheellppeerr ((ooppttiioonn))
WWAARRNNIINNGG -- Always use two people to attach or remove the patient helper.
CCAAUUTTIIOONN
• Always secure the lifting pole in the mounting bracket before you adjust the patient helper.
• Always remove the patient helper before transporting the product.
You can attach the patient helper into the patient helper mounting bracket at the head end of the product.
To attach the patient helper:
1. Insert the lifting pole (A) into the mounting bracket (B) (Figure 22).
2. Rotate the lifting pole in the mounting bracket until the patient helper knob (C) locks in position (Figure 22).
5900-009-001 Rev A.4 39 EN
