44..44..22.. TToo UUssee tthhee SSeeccoonnddaarryy SSppeecciimmeenn CCoolllleeccttiioonn BBaasskkeett
NNoottee -- The specimen collection manifold contains a secondary specimen collection basket as a back-up method to
collect specimens in the event that a specimen collection tray was not inserted in the manifold while suctioning the
specimen material.
NNoottee -- The secondary specimen collection basket is not intended to be used as a primary means of specimen
collection.
1. To access the secondary specimen collection basket in the manifold, touch the STOP SUCTION button on the main
control panel display to stop fluid suction (Figure 30). Disconnect the suction tubing from the manifold port.
FFiigguurree 3300 –– SSttoopp tthhee SSuuccttiioonn
2. Push the EJECT button to release the specimen collection manifold from the rover receptacle (Figure 31).
FFiigguurree 3311 –– EEjjeecctt tthhee MMaanniiffoolldd
3. Remove the manifold from the rover. (Figure 32)
FFiigguurree 3322 –– RReemmoovvee tthhee MMaanniiffoolldd
700000969828 Rev-AA 45 EN
