ZUMA - High Current DC Power Supply User Manual
®
pg 5
• Zuma dimensions 6.8” x 3.3” x 1.8” (173mm x 84mm x 46mm)
• Zuma weight 1.25 lbs. (680g)
• Zuma Input 100-240V AC 50/60Hz
• Zuma 9V DC Outputs Seven (5) 9V DC, 500mA, center-negative
• Zuma Adjustable Outputs Two (2) Selectable 9V DC (500mA), 12V DC (375mA), or 18V DC (250mA)
center-negative
• Zuma high-current DC power supply
• IEC cable (region-specific)
• Nine (9) 2.1mm x 5.5mm pedal cables (24” long, straight to right angle barrel connectors)
For additional help with setup, connections, power, and mounting, please
visit strymon.net/support/zuma or email us at support@strymon.net.
• 9 high-current, fully isolated outputs
• 9 outputs offer 9V DC option
• 500mA per 9V DC output powers nearly any pedal
• 2 selectable outputs offer 9V, 12V, or 18V DC options
• 12V option provides 375mA, 18V provides 250mA
• 9 pedal cables included (5.5mm x 2.1mm barrel connectors, center negative, right angle to straight cables)
• Detachable IEC power cable included
• 24V OUT jack allows connection to additional outputs via Strymon Ojai (sold separately)
• Nine individual custom transformers (one per channel) deliver clean, consistent power
• Worldwide power compatibility ensures no-hassle international touring
• Energy efficient, compact design
• Lightweight and rugged anodized midnight blue aluminum chassis
• Fits under most pedalboards
• PedalTrain mounting bracket available (sold separately)
• Designed and built in the USA
Features
Specifications
What’s In the Box?
Questions?
INS & OUTS
TECHNOLOGY
CONSTRUCTION
