Stulz Ultra Series User Manual

STULZ Ultra-Series Humidifier Controller
(August, 2013) 43
Remote On/Off:Enabled
Invert:Yes
Position:Closed
Customer AL 1: Disabled
Invert:Yes
Position:Closed
Shutdown:Disabled
Airflow Sw :Enabled
Invert:Yes
Position:Closed
Pin 4: None
Invert:Yes
Position:Closed
Smoke Detect :Disabled
Invert:Yes
Position:Closed
High Hum Lim :Disabled
Invert:Yes
Position:Closed
Customer Al 2:Disabled
Invert:Yes
Position:Closed
Shutdown: No
Freeze Alarm :Disabled
Invert:Yes
P
osition:Close
d
Customer Al 3:Disabled
Invert:Yes
Position:Closed
Shutdown: No
Group Select :Disabled
Invert:Yes
P
osition:Closed
The input may have the ability to be enabled or disabled.
Some inputs cannot be disabled.
Invert allows the polarity of the signal to be set. “Yes”
means to interpret an Open as On and Closed as Off. “No”
means to interpret an Open as Off and Closed as On.
The Position is the current state of the input, Open or
Closed to ground.
Some inputs may have the ability to shut down the system
when the input is On and the enabling or disabling of that
shutdown is included in the screen.
5.6.1.2.1 Remote and Customer Alarm 1 Setup
5.6.1.2.2 Airflow Switch and Pin 4 Function Setup
Pin 4 can be configured to be None, Water Detector or
Condensate Pan.
5.6.1.2.3 Smoke Detector and High Humidity Limit
Switch Setup
5.6.1.2.4 Customer Alarm 2 and Freeze Alarm Setup
5.6.1.2.5 Customer Alarm 3 and Group Select Setup
5.6.1.3 Factory Options
5.6.1.3.1 Timers and Miscellaneous Setup
Sensor fail delay masks the failure alarm to make sure the
sensor has really failed.
Digital Input Setup is
Digital Input Setup is
Digital Input Setup is
Digital Input Setup is
Digital Input Setup is
Digital In
OPTIONS
Modbus
FACTORY Support if
Sensor fail delay: 15s
Clock Adjust: 3600
Disp Timeout: Enabled
Disp Backlite Dly:300s
Humd Comm Timeout: 60s
T
imers, misc setup
