3DIMENSIONSHBASE STÛV16
.1 DIMENSIONS
SIDE VIEW FRONT VIEW
DESCRIPTION 16-58 16-68 16-78
H base AW1301001200 AW1301001300 AW1301001400
17 ⁄" A
39 ¾"
15 ¾"
⁄"
4"
2 ¾" 2 ⁄"
1 ⁄"
4 ⁄"
2 ⁄"
11 ¾"
3 ⁄"
2 ⁄"
2 ½"
11 ⁄"
BOTTOM VIEW
M6x16 hex bolts
(4x)
3
5
2
Stûv 16-Cube
(sold separately)
H base
4
2
3
5
1
OPTION : AW1200200700
Outside air intake connector
M4 nuts (x4)
Air inlet channel
Cylindrical connector
Self-drilling screws (x2)
Offset reducer
4
1
.2 EXPLODED VIEW
1
Non-combustible*
Non-combustible*
*See Stûv 16-cube installation
manual for more details .
FRONT
VIEW
A
16-58 22 ⁄ "
16-68 26 ¾"
16-78 30 ¾"
