Stuv 21 - Page 3

2. SPECIFICATIONS
STU
^
V 21 | MODEL SPECIFICATIONS
PAGE 3
SINGLE FRONTED MODEL - STUV 21
DIMENSIONS (mm)
OTHER DETAILS
STUV 21 / 95 SF STUV 21 / 105 SF STUV 21 / 125 SF STUV 21 / 135 SF
OUTPUT KW
10kw to 18kw 7kw to 19kw 11kw to 23kw 11kw to 21kw
HEATING CAPACITY
120m
2
125m
2
145m
2
130m
2
MINIMUM FLUE HEIGHT
4.5m 4.5m 4.5m 4.5m
WEIGHT
(excluding zero clearance casing)
292kg 224kg 305kg 286kg
MAX LOG SIZE
60cm 80cm 100cm 100cm
ACTIVE FLUE SIZE
STUV 21 / 95 SF STUV 21 / 105 SF STUV 21 / 125 SF STUV 21 / 135 SF
A
950 1050 1250 1350
B
1455 1040 1295 1040
C
590 496 563 500
D
770 870 1070 1170
E
615 400 535 400
ACTIVE FLUE SIZE
300mm,350mm
ADDITONAL FLUE LINERS
250mm
250mm
300mm,350mm
250mm,300mm
200mm 300mm
350mm,400mm
