INSTALLATION INSTRUCTIONS
3. Surface Mount
1. LOOSEN the horizontal adjustment (In and Out)
screw on hinge (AA).
2. Slide the hinge (AA) forward.
3. TIGHTEN the horizontal adjustment screw into
place with screw to the rear of the slot.
4. LOOSEN lateral adjustment (In and Out) screw until
screw resists.
3
1
2. Surface Mount
Hold the cabinet (A) at the desired position on wall.
NOTE: Make sure the cabinet is level.
Mark locations on wall through mounting holes in back
of cabinet (A).
Drill holes in the marked spots.
Attach the cabinet (A) to the wall, using mounting
screws
(not included)
and drywall anchors
(not included)
.
2
A
2
3
4
AA
AA
AA
