Style selections TPGAZ2236 - Hardware Used 2

2.1 Connect the short cross beam L (B3) and the short cross beam R (B4) by bolt (BB) / (FF) / (II), then
tighten them with wrench (JJ). Place cap (HH) on the bolt heads and cap (GG) on the nut.
2.2 Connect the beam connector (F2) with the cross beams (B3/B4) by bolt (AA) / (FF) , then tighten
them with wrench (JJ). Place cap (HH) on the bolt heads .
Repeat the step for another assembly.
