9
Over-and-under models:
First, unload the
freezer baskets. To remove the upper freezer
basket, lift up on the front and pull forward to
release the basket. To remove the lower freezer
basket, lift the basket directly upward and out.
Refer to the illustration below.
To r eins tall the lower fre ezer basket, ins ert t he
basket into the four corner retainers. To reinstall
the upper freezer basket, position the basket
onto the slide rails. Slide the basket towards the
back. You should hear an audible click when the
engagement is made.
IMPORTANT NOTE:
Unload the freezer baskets
before removing.
FREEZER STORAGE
FREEZER BASKET REMOVAL
All freezer and side-by-side models:
First,
unload the freezer basket. To remove the basket,
pull it out until it stops. Behind the bottom two
corners of the front face of the basket are metal
clips. Pull these clips toward the front of the
basket and lift and rotate the basket up.
IMPORTANT NOTE:
To r emov e the bas kets from
Models ICBBI-36S, ICBBI-42S or ICBBI-42SD, the
basket must be raised and pulled through the
opening in the door liner after disengaging the
basket from the slides.
IMPORTANT NOTE:
If Models ICBBI-36F or
ICBBI-36S are limited to a 90° opening, it may be
necessary to remove the basket and/or shelf
above in order to remove the basket.
To r eins tall, pus h the dra wer s lides b ack into the
freezer. Align the basket with the slides, and
push the basket straight back onto the slides
until it stops. Press downward on the front of the
basket to engage the basket clips with the slides.
Models ICBBI-42SD and ICBBI-48SD:
To
remove the ice bucket, pull the bucket out part of
the way, then rotate the right side of the bucket
as you continue to pull the bucket out. Refer to
the illustration below.
ICE BUCKET REMOVAL
Over-and-under models and Model ICBBI-36F:
To r emov e the ice buck et, p ull the f reez er dr awer
or basket out until it stops and lift the ice bucket
out.
Models ICBBI-36S, ICBBI-42S and ICBBI-48S:
To r emov e the ice buck et, p ull the b ucke t for-
ward until it stops. Next, lift the bucket to clear
the carrier assembly along the back edge of the
bucket. Once the bucket has cleared the
assembly, continue to pull forward and out. If the
door is limited to a 90° opening, repeat the pro-
cedure, but when lifting the ice bucket out, pivot
the right side of the bucket toward you and out.
This will allow the ice bucket to clear the door.
Refer to the illustration below.
Freezer basket removal—all freezer
and side-by-side models
Freezer basket removal—
over-and-under models
Ice bucket removal—Models
ICBBI-36S, ICBBI-42S and ICBBI-48S
Ice bucket removal—Models
ICBBI-42SD and ICBBI-48SD
SUB-ZERO BUILT-IN USE & CARE
